WYNBERG

Gear Oils

SF-412 | Synthetic Ultra High Temperature Gear Oil
SF-400 | Synthetic High Temperature Gear Oil
SF-440 – SYNTHETIC PAG GEAR OIL

SF-412 | Synthetic Ultra High Temperature Gear Oil

Product Name/CodeSF-412
ClassificationSynthetic Ultra High Temperature Gear Oil
Viscosity Classes46,68,120,180,220,320
Temperature Range-30°C to 350°C
PACKAGING10L,20L,25L & 210L Barrels
Application AreaRecommended for use in high speed or high load operating environments and in control chain, open gears, low speed, enclosed gear and worm gear drives. Based on PAO (SHC).



SF-400 | Synthetic High Temperature Gear Oil

Product Name/CodeSF-400
ClassificationSynthetic High Temperature Gear Oil
Viscosity Classes100, 150, 220, 320, 460
Temperature Range-40°C to 290°C
PACKAGING10L,20L,25L & 210L Barrels
Application AreaSF-400 Series gear oils are designed for all gearboxes. They are PAO (SHC) based.



SF-440 - SYNTHETIC PAG GEAR OIL

GENERAL DESCRIPTION:

SF-440 gear oils are fully formulated synthetic lubricants specially designed for use in highly rated worm gear units. They have an extremely high viscosity index, low pour points, and high load-carrying capacities, and show exceptionally low coefficients of friction. Additives are incorporated to reinforce the stability of these oils, their resistance to corrosion, and their resistance to scuffing under unfavourable operating conditions. These oils are capable of extremely long service life.

SELCO SF-440 being POLYGLYCOL, and not mineral oil-based, exhibits inherently superior properties particularly with respect to outstanding thermal stability and lubrication performance. These properties are particularly useful in heavily loaded mechanisms operating at elevated temperatures, e.g., worm gears and calendar bearings.

APPLICATIONS:

SELCO SF-440 is suitable for heavy-duty automotive and industrial gearboxes with sump temperatures up to 140°C. The product performance allows for extended drain intervals and even, in some cases, for operation as a “fill for life” lubricant.

The specially developed polyglycol-additive technology of the new SELCO Synthetic Industrial Lubricants SF-440/220 and SF-440/460 allows thermal stable operation at temperatures in excess of 200°C. These products are therefore preferred for the lubrication of gears and bearings operating at elevated temperatures, e.g., in calendar equipment.

Description

PROVEN BENEFITS:

TYPICAL PROPERTIES:

Properties

Test Method

ISO GRADE





80

120

220

320

460

Viscosity cSt at 40°C

ASTM D445

80

133

236

324

458

Viscosity cSt at 100°C

ASTM D445

14

21

37

50

67

Relative Density 20/20°C

ASTM D1298

1.00

1.00

1.02

1.02

1.017

Viscosity Index

ASTM D2270

181

184

210

219

223

Flash Point °C

ASTM D92

260

260

290

290

286

Pour Point °C

ASTM D97

-30

-30

-36

-33

-33

Neutralization Value (mgKOH/g)

ASTM D664

0.6

0.6

1.07

1.11

1.13

FZG Test Conditions A/8.3/90

IP 334

Pass

Pass

Pass

Pass

Pass

FZG Test Conditions A/16.6/140

IP 334

Stage 12

Stage 12

Stage 12

Stage 12

Stage 12

Corrosion – Copper Strip Classification

ASTM D130

1

1

1

1

1

Corrosion – Rust Prevention

ASTM D665A

Pass

Pass

Pass

Pass

Pass

Foam Tendency/Stability, Sequence 1

ASTM D892

10/0

10/0

10/0

10/0

10/0

Foam Tendency/Stability, Sequence 2

ASTM D892

10/0

10/0

10/0

10/0

10/0

Foam Tendency/Stability, Sequence 3

ASTM D892

10/0

10/0

10/0

10/0

10/0





STORAGE AND HANDLING

  • Store in a cool, dry place away from direct sunlight.
  • Keep containers tightly closed to prevent contamination.
  • Use appropriate personal protective equipment (PPE) when handling the product.
  • Dispose of used lubricant as per local environmental regulations.

Packaging Availability:

  • 5L, 20L, 200L Drums
  • Bulk Supply Available on Request



HEALTH & SAFETY:

  • Follow standard industrial hygiene practices.
  • Refer to the Safety Data Sheet (SDS) for detailed handling and disposal information.

For more information, contact:
SELCO Lubricants | Website: https://www.wynbergindustries.com | Email: info@wynbergindustries.com

DISCLAIMER

The information provided in this technical data sheet is based on our best knowledge and experience. However, no warranty is given, either expressed or implied, regarding the accuracy of the data or the results obtained from using the product. Users should evaluate the product under actual service conditions to determine suitability for their specific application.
